compas_manifold

Robust, guaranteed-manifold mesh booleans for COMPAS, powered by Manifold. Every operation returns a valid, watertight 2-manifold — no precision tuning, no degenerate-input crashes.

By Petras Vestartas, Block Research Group, ETH Zürich. Built on Manifold (Emmett Lalish) and nanobind (Wenzel Jakob).

Features

Function	Description
boolean_union_mesh_mesh(A, B)	Union of two meshes
boolean_difference_mesh_mesh(A, B)	Difference A - B
boolean_intersection_mesh_mesh(A, B)	Intersection of two meshes
split_mesh_mesh(A, B)	Split A with B
boolean_chain(meshes, operations)	Left-folded chain of ops, evaluated in C++
boolean_batch(meshes, operation)	Single op across many meshes via BatchBoolean
boolean_chain_with_face_source(meshes, operations)	Chain + per-face source tracking
boolean_difference_mesh_meshes(A, Bs)	Subtract many cutters from A in one batch

Quick start

from compas.geometry import Box, Sphere, Polyhedron
from compas_manifold.booleans import boolean_difference_mesh_mesh

A = Box(2).to_vertices_and_faces(triangulated=True)
B = Sphere(1.0, point=[1, 1, 1]).to_vertices_and_faces(u=32, v=32, triangulated=True)

V, F = boolean_difference_mesh_mesh(A, B)
shape = Polyhedron(V.tolist(), F.tolist())

See Installation and the Examples.
